Printing

  Print Method

Thermal Transfer / Direct Thermal

  Print Resolution

300 DPI

  Print Speed

2~6 inch/s (51-152mm/s)

  Max. Print Width

108 mm(4.25")

  Max. Print Length

2286mm (90")

  Dot Density

300dots/inch (12dots/mm)

  Dot Size

0.125x0.125mm (1mm=11.8dots)

  Interface

USB+Parallel+Serial+Ethernet

Ribbon

  Ribbon OD

Max.67mm

  Ribbon Length

Max.300m

  Ribbon Core Size

1 inch (25.4mm)

  Ribbon Width

Max.110mm,  Min.30mm

  Ribbon Rolling Up Method

Outward Rolling

Media

  Paper Roll OD

127mm (5")

  Paper Type

Continuous paper, Marked paper, Label paper, Perforated paper, etc.

  Paper  Rolling Up Method

Printing side outward rolling

  Paper Width

Max.120mm (4.72")   Min.20mm (0.78")

  Paper Thickness

Max. 0.254mm (10mil)   Min. 0.06mm (2.36mil)

  Paper Roll Core Size

25.4mm~38mm (1"~1.5")

  Paper Gap

Min. 2 mm (0.09")

  Label Length

10~2286mm (0.39"~90")

Remark: If label length is less than 25.4mm(1 inch), the label paper with perforated line are recommended in order to tear off the labels easily.

Specifications

  Printer Dimensions

290x196x179mm (LxWxH)

  Printer Weight

Approx. 2.5KG

  Power

 Input: AC 110V/240V      Output: DC24V/2.5A，60W

  Operation Condition

Temperature: 5~45℃(41~104℉),  Humidity: 25~85%RH

  Storage Condition

Temperature: -10~50℃(-10~140℉), Humidity: 10%~90%RH

  Print Head

50KM

Software

  Editing Software

Nicelabel  SE

  Driver

Windows 2000, XP, Vista, Win7, Win8, Win10, Windows Server 2003&2008

  DLL

Windows 2000, XP and Vista

Fonts

  Enlargement&Rotation

1 to10 times enlargement in both directions; 0°、90°、270°、360°rotation

  Character Size

FONT O to FONT 8

Barcode

  1D Barcode

Code39, Code93, Code128UCC subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8

EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, china

POS, ITF14

  2D Barcode

QR code

  Graphics Processing

Support BMP/PCX/BAS  files

  Accessories

Standard External Media Holder
