Model:

EBP1125TT-E

Dimontion

210(W)×180(H)×285(L)

Weight

2.09KG

Power supply

Input: AC 110-240V

Output: DC 24V 2.5A,60W

（built-in power adapter）

Environment

Work environment：temperature 5~40℃ (41~104℉)，humidity 25~85%

Storage：temperature-40~60℃ (-40~140℉)，humidity  10~90%

Interface

Serial+USB+Ethernet+Parallel

Model

EBP1125TT-E

Dot density

203dots/inch(8dots/mm)

Print method

Ribbon/Thermal

Dot size(W×L)

0.125×0.125 mm (1 mm = 8 dots)

Print speed（inch/s）

2~5 inch/s

Maximum print width

108 mm(4.25")

Maximum print length

2286 mm(90")

Pulse excitation

1*108 pulse

Thermal film(reliability)

50KM

Ribbon diameter

Max. 67 mm

Ribbon length

300m

Ribbon axis siza

1 inch (25.4 mm)

Ribbon width

Max. 110 mm

Min. 30 mm

Ribbon winding method

outward winding

Model

EBP1125TT-E

Paper roll diameter(Max.)

127 mm(5")OD

Paper type

Continuous paper , paper with interspaces , folding paper ,black mark paper

Paper rolling up method

Printing side outward rolling / inward rolling

Paper width

Max.120 mm(4.72")

(upper & bottom paper)

Min.20 mm(0.78")

The thickness of the paper

Max.0.254 mm(10 mil)

(upper & bottom paper)

Min.0.06 mm(2.36 mil)

Paper roll axis size

25.4 mm~38 mm(1"~1.5")

Label length

10~2286 mm(0.39"~90")

Remark:  If label length less than 25.4mm(1 inch), label paper with perforations are recommended, labels can be torn off easily.

Gap size

Min.2 mm(0.09")

Editing Software

Nicelabel  SE

Driver

Windows 2000、XP、Vista、Windows 7/8/8.1/10、Windows Server 2003&2008
